Specifications:
| Focal Length | 75mm | F Number(#) | 1.4 |
| FOV(HxV) | 5.86°x4.69° | Detector | 640x512-12μm |
| Wavelength Range | 8~12 micro | DFOV | 30.4° |
| Operation Temperature Range | -40℃~60℃ | Coating | DLC or AR |
| Minimum Working Distance | 5m | Distortion | Maximum D-FOV Distortion:<1% |
1.20°MTF(@42lp/mm)
2.20°Field curvature and distortion
3.Vignetting
